SATO CT400 - Font, Raster

Font, Raster
Command Structure <ESC>A<ESC>RDabb,ccc,ddd,nn. . .n
a = A CG Times font style
B CG Triumvirate font style.
bb = 00 for Normal font
01 for Bold font
ccc = Horizontal size (16 - 999 dots or P08 - P72)
ddd = Vertical size (16 - 999 dots or P08 - P72)
nn..n = Data to be printed.
Example: <ESC>RFA00,014,018ABCD
Placement: Within normal command stream
Default: None
Command Function To print point size characters created using font definitions.
Input to Printer
<ESC>A
<ESC>V0100<ESC>H0100
<ESC>RDA00,014,018ABCD
<ESC>V0200<ESC>H0100
<ESC>RFB10,018,014ABCD
<ESC>Q1<ESC>Z
Printer Output
Special Notes 1. The “cccc” Horizontal Size and “dddd” Horizontal Size parameters
can be entered either in dots or points, but both parameters must
use the same value types. If point size is used, the point size is
preceded by a “P”.
Not
Implemented
Label Sample TBA
Section 4. Programming Reference
SATOCT SeriesPrinters9001069A Page4-37
