Section 10: Diagrams & Schematics
M84Pro Service Manual PN 9001111A Page 10-15
PEEL-OFF, PEEL-OFF SENSOR, NO BACKFEED
Figure 10-16, Operation Sequence Chart
Peel-off
Pitch sensor
(g
a
p)
Print 1
st
page
Standby
Head
d e f
c
d e fc g
Note 1: Peel-off senor check
N
ote 2: Unprintable area
Peel-off senso
r
N
ote 1: The peel-off sensor checks the peel-off status of the label, and does not move to the next operation until the label
is peeled.
N
ote 2: Because backfeed operation is not performed, an unprintable area occurs at the front.
(Note)
Above is the base reference position when the gap sensor is used.
