Section 10: Diagrams & Schematics
M84Pro Service Manual PN: 9001111A Page 10-16
PEEL-OFF, PEEL-OFF SENSOR, OPERATION 1
Figure 10-17, Operation Sequence Chart
Peel-off
Pitch sensor (gap)
Print 1
st
page
Standby
Head
d e f
c
d e
f
c
g
Note 1: Peel-off sensor check
Peel-off sensor
Note 1: The peel-off sensor checks the peel-off status of the label, and does not move to the next operation until the label i
s
peeled.
(Note)
Above is the base reference position when the
g
ap sensor is used.
Note 1: Peel-off sensor check
Label peel-off
d e f
c
g
d e f g
Backfeed
