Section 10: Diagrams & Schematics
M84Pro Service Manual PN 9001111A Page 10-17
PEEL-OFF, EXTERNAL PULSE INPUT, NO BACKFEED
Figure 10-18, Operation Sequence Chart
Peel-off Pitch sensor
(g
a
p)
Print 1
st
page
Standby
Head
d e f c
d
e fc
g
Print signal input
N
ote 1: Unprintable area
N
ote 1: Because backfeed operation is not performed, an unprintable area occurs at the front.
(Note)
Above is the base reference position when the gap sensor is used.
