sauter ASV3 User Manual

Page 31 of 45
BACNET
OBJECT
ID
BACNET
OBJECT NAME
DESCRIPTION
UNIT
OBJECT TYPE
READ/
WRITE
NOTE
control (Internal
Use)
BO8
DO0
DO0 for 24VAC
-
Digital Output
RW
Selected
Model only
BO9
DO1
DO1 for 24VAC
-
Digital Output
RW
Selected
Model only
8.2 TABLE 2: BACNET OBJECT LIST FOR ANALOG VALUES
BACNET
OBJECT
ID
BACNET OBJECT
NAME
DESCRIPTION /
RANGE
UNIT
DEFAULT
VALUE
READ/
MODBUS
WRITE ID
NOTE
AV0
BACnet device
instance
number
0-9999
-
1000
R
R0
(HMI)
The value in
PC
configuration
software must
be divided by
10.
AV1
DDC Program
Version
0-999999999
-
-
R
R1
-
AV2
VAV box K
factor
0-1000
-
100
RW
R2
(HMI)
-
AV3
VAV box inlet
diameter mm
100=4”
125=5”
150=6”
200=8”
250=10”
300=12”
350=14”
400=16”
mm
150
RW
R3
(HMI)
-
AV4
Current VAV
airflow
0-9999
LPS,
CFM,
CMH
-
R
R4
(HMI)
-
AV5
VAV demand
airflow
0-9999
LPS,
CFM,
CMH
-
RW
R5
-
AV6
Forced airflow
control
0-9999
LPS,
CFM,
CMH
-
RW
R6
(HMI)
-
AV7
Cooling
maximum
airflow
AV8-9999
LPS,
CFM,
CMH
30
RW
R7
(HMI)
-
AV8
Cooling
minimum
airflow
0-AV7
LPS,
CFM,
CMH
10
RW
R8
(HMI)
-
AV9
Heating
maximum
airflow
AV10-9999
LPS,
CFM,
CMH
30
RW
R9
(HMI)
-
