sauter ASV3 User Manual

Page 30 of 45
8 BACnet Objects List
8.1 TABLE 1: BACNET OBJECT LIST FOR CONTROLLER INPUTS/OUTPUTS
BACNET
OBJECT
ID
BACNET
OBJECT NAME
DESCRIPTION
UNIT
OBJECT TYPE
READ/
WRITE
NOTE
AI0
Temp
Ai0 for NTC
sensor, Digital
Input (Dry
Contact)
°C
Analog Input
(NTC), Digital
Input
R
Selected
Model only
AI1
ADC
Ai1 for 0-10VDC
VDC
Analog Input
R
Selected
Model only
AI2
NTC
For Knob
thermostat NTC
temperature
sensor (Internal
Use)
°C
Analog Input
R
AI3
VR
For Knob
thermostat VR
temperature
setpoint (Internal
Use)
°C
Analog Input
R
AI12
Air Pressure
For DP sensor
(Internal Use)
Pa
Analog Input
R
BACNET
OBJECT
ID
BACNET
OBJECT NAME
DESCRIPTION
UNIT
OBJECT TYPE
READ/
WRITE
NOTE
AI13
Air Flow
For VAV box
airflow (Internal
Use)
LPS
Analog Input
R
AO14
AO0
Ao0 For 0-10VDC
(Heating Valve
Output)
%
Analog
Output
RW
Selected
Model only
AO15
AO1
Ao1 for 0-10VDC
Vtg
Analog
Output
RW
Selected
Model only
BI4
Over Current
Actuator DC
motor over
current (Internal
Use)
-
Digital Input
RW
For Calculation
of running time
BI5
Over Current
Actuator DC
motor over
current (Internal
Use)
-
Digital Input
RW
For Calculation
of running time
BO6
Open
Damper
Damper
actuator open
control (Internal
Use)
-
Digital Output
RW
For Calculation
of running time
BO7
Close Damper
Damper
actuator close
-
Digital Output
RW
For Calculation
of running time
