2.5 Technical Specification
Power supply
Power supply
Power supply
24 V~, +/-10%, 50...60 Hz
Power consumption at nominal
voltage 50/60 Hz (~/=)
Power consumption during operation5
1.5 W
Power consumption when idle
0.5 W
Parameters
Integrated damper actuator
Angle of rotation
90° (95° mechanical)
Admissible dimensions of damper shaft
Ø 6...16 mm, □ 5. 12 mm
Admissible damper shaft (hardness)
Max. 300 HV
Surge-voltage resistance
Not supported on 24V model
Operating noise
< 42 dB (A)
∆p sensor
Measuring range ∆p (gain = 1)
0...500 Pa
Linearity error
3% of reading
Time constant
0.23 s
Influence of position
< 1 Pa
Reproducibility
0.5% FS
Zero-point stability
< 0.05 Pa / Year
Admissible positive pressure
±1 kPa
Admissible operating pressure pstat
±5 kPa
Low-pressure connections
Ø i = 3.5...6 mm
Ambient conditions
Operating temperature
0...50 °C
Storage and transport temperature
-20...70 °C
Admissible humidity
5% to 95% rh, non-condensing
Inputs/outputs
Analogue inputs
Dry contact for any kind input & Thermistor 10k
Analogue outputs
0-10V, 4-20mA ,12 bits resolution
Interfaces and communication
RS-485 not electrically isolated
9600-76800 BPS, 1200 Meters
Communication protocols
BACNET MS/TP RS485
9600-76800 BPS, 1200 Meters
BACnet BTL certification
BACnet Application Specific Controller (B-
ASC)
Access method
Client/server
Topology
Line, daisy chain
Number of participants
Up to 127 recommended 32
Bus termination
120 Ω (both ends) SW4 (S3)
Construction
Weight
0.68 kg
Fitting
Self-centering spindle adapter
Standards and directives
Type of protection
IP20 (EN 60529)
Protection class
III (EN 60730)
Conformity
Machine directive 2006/42/EC, appendix II 1.
B
EMC Directive 2014/30/EU
EN 61326 1 :2013 Electrical equipment for
measurement, control and laboratory use EMC
requirements Part 1: General requirements
EN 61326-1:2013, EN 61000-4-2:2009, EN
61000-4-3:2006+A1:2008+A2:2010, EN
61000-4-8:2010, FCC Part 15,subpart B,Class
A
