sauter ASV3 User Manual

Page 32 of 45
BACNET
OBJECT
ID
BACNET OBJECT
NAME
DESCRIPTION /
RANGE
UNIT
DEFAULT
VALUE
READ/
MODBUS
WRITE ID
NOTE
AV10
Heating
minimum
airflow
0-AV9
LPS,
CFM,
CMH
10
RW
R10
(HMI)
-
AV11
VAV damper
position (0-10)
0-10
-
-
R
R11
(HMI)
Modbus HMI
value is 10
times of this
value
AV12
VAV damper
override
position (0-10)
0-10
-
-
RW
R12
(HMI)
-
AV13
Damper
actuator travel
time
0-999
Sec
-
R
R13
-
AV14
Heating f
loating valve
travel time
0-999
Sec
50
R
R14
-
AV15
Cooling PID
parameter- Kp
0-3276
°C/ °F
(50)
RW
R15
-
AV16
Cooling PID
parameter- Ki
0-3276
%/°C
0
RW
R16
-
AV17
Heating PID
parameter- Kp
0-3276
°C/ °F
(50)
RW
R17
-
AV18
Heating PID
parameter- Ki
0-3276
%/°C
0
RW
R18
-
AV19
Dead band for
temperature
control
0-3276
°C/ °F
1
RW
R19
-
AV20
HMI
Temperature
sensor display
/Pressure
display PA
0-100
°C,Pa
-
R
R20
(HMI)
-
AV21
HMI Humidity
sensor display
/ID address
0-100
%RH
-
R
R21
(HMI)
For EY-
RU305F7002W
H and EY-
RU305F7003W
AV22
PPM/RPM/Time
display select
0-100
-
-
R
R22
For EY-
RU305F7003W
AV23
HMI
Temperature
sensor
0-100
°C/ °F
-
R
R23
(HMI)
-
AV24
HMI Humidity
sensor
0-100
%RH
-
R
R24
(HMI)
For EY-
RU305F7002W
and EY-
RU305F7003W
AV25
HMI CO2 sensor
0-9999
PPM
-
R
R25
(HMI)
For EY-
RU305F7003W
