BACNET
OBJECT
ID
BACNET OBJECT
NAME
DESCRIPTION /
RANGE
UNIT
DEFAULT
VALUE
READ/
MODBUS
WRITE ID
NOTE
AV103
AV-103
°C value of cooling
temp setpoint high
limit
°C
-
RW
-
-
AV104
AV-104
°F value of cooling
temp setpoint high
limit
°F
-
RW
-
-
AV105
AV-105
1 stage heating
temp. setpoint
-
-
RW
-
-
AV106
AV-106
°F value of temp set
point low limit
°F
-
RW
-
-
AV107
AV-107
°C value of temp
set point low limit
°C
-
RW
-
-
AV108
AV-108
2 stage heating
temp. setpoint
-
-
RW
-
-
AV109
AV-109
Cooling output for
airflow PID
calculation
%
-
R
-
-
AV111
AV-111
Setpoint Value for
Cooling
temperature PID
°C
-
R
-
-
AV112
AV-112
Present Value for
Cooling
Temperature PID
°C
-
R
-
-
AV113
AV-113
Actual airflow -
filtered
LPS
-
R
-
-
AV114
AV-114
Not use
-
-
-
-
-
AV115
AV-115
Counter (0-AV117)
-
-
R
-
-
AV116
AV-116
Not use
-
-
-
-
-
AV117
AV-117
Output sampling
2.2sec
-
2.2
RW
-
-
AV118
Demand VAV
Position
VAV position
control output, 0-
100
%
-
R
-
-
AV119
AV-119
Counter for DP
changes, 0-25
-
-
RW
-
-
AV120
AV-120
Heating f loating
output, 0-100
%
-
R
-
-
AV121
VAV Off-min
position
0-100
%
20
R
-
BV59 is the
mode select
for this
AV122
AV-122
Arithmetic
Operation (AV75-
AV124)
-
-
R
-
-
