sauter ASV3 User Manual

Page 38 of 45
BACNET
OBJECT
ID
BACNET OBJECT
NAME
DESCRIPTION /
RANGE
UNIT
DEFAULT
VALUE
READ/
MODBUS
WRITE ID
NOTE
AV123
AV-123
Arithmetic
Operation
(AV75+AV124)
-
-
R
-
-
AV124
AV-124
Dead band for air f
low control
-
(5)
RW
-
-
AV125
AV-125
Arithmetic
Operation Air f low
unit
LPS
-
R
-
-
AV126
AV-126
Air f low display for
HMI
-
-
RW
-
-
AV127
AV-127
Humidity offset for
HMI
%
-
RW
-
-
NOTE:
AV object Present value corresponds to MODBUS Holding Register: av0 ~ av499 corresponds to
40001~4500, the value is 10 times the symbol integer (Present Value -3276.8~3276.7 correspond to -
32768~32767). If AV default value is in (), the value is fixed and can only be changed in DDC
programming.
8.3 TABLE 3: BACNET OBJECT LIST FOR BINARY VALUES
BACNET
OBJECT
ID
BACNET OBJECT NAME
READ/
WRITE
MODBUS
ID
NOTE
BV0
Master/Slave
Mode,
Slave = 0,Master =1
-
RW
C0
-
BV1
VAV box
Occupied/
unoccupied
Unoccupied=0,
Occupied=1
-
RW
C1 (HMI)
BV2
Cool/Heat
mode
Cooling = 0,Heating = 1
-
RW
C2 (HMI)
BV3
HMI
Temperature
display type_
Present
value/ Set
point value
Present value=0, Set point
value=1
-
RW
C3 (HMI)
BV4
BV-4
BV-4
-
-
C4
BV5
Override
airflow
control
No =0,Yes=1
-
RW
C5 (HMI)
BV6
Damper
override
No =0,Yes=1
-
RW
C6 (HMI)
BV7
Override
VAV airflow
No =0,Yes=1
-
RW
C7 (HMI)
