If a hitch sensor signal of the tractor is used to
automatically activate and deactivate (GO key)
the plough steering system on the headland, it is
possible to invert the signal by checking the
invert hitch signal.
Tap on the blue arrow to the right in the screen to
get more information about the visualized plough
measurements from the main screen.
Offsets
Figure 61 shows the offsets window for the
SBGuidance Vario-plough. Refer to chapter 5.1.1
for defining the offsets of the tractor.
Tap on the pencil symbol next to Plough. The
reference point for the headland signal must be
positioned in the centre of the ploughing width.
Determine on the plough where the reference
point will be and then measure the Cf distance to
the connecting points of the cross-shaft.
Figure 61 SBGuidance Vario-plough offsets
