01:01-02
©
Scania CV AB 1997 41
Program 96
4. Place the heated ring gear on the flywheel so
that the chamfer on the teeth faces the starter
motor. Make sure that the ring gear abuts
firmly against the flywheel.
5. If necessary, tap the ring gear in place using a
plastic mallet.
6. The ring gear must not be cooled rapidly but
must cool down in the open air.
Changing crankshaft seal
1. Bolt the inner part of assembly tool 98 321 to
the crankshaft flange.
2. Fit the outer part of assembly tool 98 321 and
screw it in until it abuts against the seal. Then
screw in the set screw against the inner part
and lock the wing nut.
3. Remove the tool and prise out the seal using
tool 98 484 and a screwdriver.
