40
©
Scania CV AB 1997 01:01-02
Program 96
Removing flywheel
1. Remove the bolts and washer.
2. Pull the flywheel off the crankshaft using
puller bolts 87 368.
Changing the support bearing,
if fitted
1. Tap the support bearing out of the flywheel
using a drift.
2. Fit a new support bearing using drift 98 433.
Changing the ring gear
- Change the flywheel ring gear if the teeth have
become so worn that the starter motor drive
does not engage.
1. Grind as deep a groove as possible in the ring
gear and split it using a cold chisel. Remove
the ring gear from the flywheel.
2. Clean contact surfaces on the flywheel using
awirebrush.
3. Heat the new ring gear so that it is at an even
temperature of about 100-150 °C.
