56
©
Scania CV AB 1997 01:01-02
Program 96
Fitting
1. Be particularly careful to clean all oilways in
the crankshaft, pivot pins and contact sur-
faces for bearings and caps.
2. Check that the dimensions of bearings and
thrust washers are correct. Fit the bearing
halves in block and cap. Generously lubricate
bearings and pivot pins.
3. Carefully lift in the crankshaft. Fit the thrust
washers and place the caps as marked.
4. Lubricate the bolt threads and start by tight-
ening the cap bolts to 90 Nm. The tighten the
bolts to 290 Nm.
Check that the crankshaft rotates easily.
5. Check crankshaft axial clearance. It should be
0.14-0.37 mm. The clearance can be adjusted
by changing the thrust bearing washers.
6. Fit pistons, connecting rods and oil pump.
7. Fit the fan bearing and fan, oil sump, timing
gear housing and intermediate gear.
8. Fit the flywheel and flywheel housing.
9. Fit the cylinder heads and pushrods.
