Schaeffler Technologies
BA 68
45
Start screen
for group management
with group fields
For further information on the colour coding and designation
of alarms, see page 79.
Input Group field Description
[
Groups
]
Alarm status
Status: Normal or
suspect
A grey symbol indicates a normal or
suspect status (level 1 to 2 in the state
diagram), i.e. no or low alarm level.
No immediate response necessary.
Status: Warning A yellow symbol indicates a pre-alarm
(level 2 to 3 in the state diagram),
i.e. a high alarm level.
Inspect the asset and schedule repair
measures for the next regular servicing
interval.
Status: Severe A red symbol indicates a main alarm
(level 3 to 4 in the state diagram),
i.e. the highest alarm level.
Inspect the asset and, depending on
the result, schedule a repair as soon as
possible.
[
Groups
]
Battery status
[
Battery Low
] Displays the battery status.
[
Groups
]
Receiving status
[
Data Not Received
Recently
]
Shows that the sensor is offline and
has not transmitted any data in the last
24 hours.
[
Groups
]
Filtered groups
For example:
[
Learning mode
]
Displays the groups compiled
on the basis of search filters.
[
My Groups
] [
Favorites
]
Other dedicated
groups,
e.g.: [
Pumps
]
Displays user-defined groups.
