www.scheppach.com
GB
|
39
* The maximum achievable splitting force is dependent
on the resistance of the log and can differ due to varia-
ble contributing factors on the hydraulic system.
** Operating mode S6 40%, uninterrupted periodic op-
eration with intermittent load. The mode comprises of
a start-up period, a time with constant load and an idle
time. The operating time is 10 mins, the relative duty
cycle is 40% of the operating time.
Noise
The noise levels have been determined in accordance
with EN 62841.
Sound pressure level L
pA
89.6 dB
Uncertainty K
pA
3 dB
Sound power level L
WA
102.6 dB
Uncertainty K
WA
3 dB
Wear hearing protection.
Excessive noise can result in a loss of hearing.
The specied noise emission values have been meas-
ured in accordance with a standardised test procedure
and can be used to compare one power tool with an-
other.
The specied device emissions values can also be
used for an initial estimation of the load.
Warning:
• The noise emission values can vary from the spec-
ied values during the actual use of the power tool,
depending on the type and the manner in which the
power tool is used, and in particular the type of work-
piece being processed.
• Try to keep the stress as low as possible. For exam-
ple: Limit working time. In doing so, all parts of the
operating cycle must be taken into account (such as
times in which the power tool is switched off or times
in which it is switched on, but is not running under
a load).
8. Unpacking
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Injuries due to the workpiece being ejected at high
speed due to improper holding or guiding.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Switch off the device and pull out the mains plug be-
fore carrying out any setting or maintenance work.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the “Safety In-
structions” and the “Intended Use” together with the
operating manual as a whole are observed.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet. Use the tool that is recommended
in this operating manual.
• This is how to ensure that your machine provides
optimum performance.
• Keep your hands away from the working area when
the machine is in operation.
7. Technical data
Compact 8t
Dimensions D/W/H mm 850/900/990
Swivel table height mm
390
Working height mm 920
Min./max. wood length cm 68 / 107
Min./max. wood diameter cm 8/35
Splitting force max. t*
7,95
400V 230V
Feed speed cm/s 5,5 3,2
Return speed cm/s
17 16
Oil quantity ml 480
Weight kg 126 125
Drive
Mains power connection 400V
3N~/50Hz 230V 1~/50Hz
400/50 230/50
Rated input P1 W 3500 3150
Power output P2 kW 2500 2300
Operating mode S6 40% **
Speed 1/min 2800
Motor protection
Yes
Phase inverter at 400V
Subject to technical changes!
