14 Mode of operation FS(L)
Operating Manual Linear ACTUSAFE CMFS(L)
OM-ENGLISH-Failsafe-Linear-16xx-V2.00-2022.03.03
14 Mode of operation FS(L)
14.1 CM03FS(L)
ON-OFF & INCHING operation
CM03FS(L)_30/5 CM03FS(L)_50/8 CM03FS(L)_100/12
S2 - 15 minutes according to IEC
60034
S2 - 15 minutes according to IEC
60034
S2 - 15 minutes according to IEC
60034
2,5 - 72 RPM 2,5 - 72 RPM 2,5 - 72 RPM
F
max
= 8,2 kN F
max
= 19,4 kN F
max
= 16,4 kN
F
avg
= 5 kN F
avg
= 8 kN F
avg
= 12 kN
Life time
*
10.000 cycles 10.000 cycles 10.000 cycles
MODULATING operation
CM03FS(L)_30/5 CM03FS(L)_50/8 CM03FS(L)_100/12
S4 - 1.200 c/h - max. 50% DC
according to IEC 60034
S4 - 1.200 c/h - max. 50% DC
according to IEC 60034
S4 - 1.200 c/h - max. 50% DC
according to IEC 60034
2,5 - 36 RPM 2,5 - 36 RPM 2,5 - 36 RPM
F
max
= 8,2 kN F
max
= 19,4 kN F
max
= 16,4 kN
F
avg
= 5 kN F
avg
= 10 kN F
avg
= 12 kN
Life time
*
1.800.000 starts 1.800.000 starts 1.800.000 starts
CONTINUOUS MODULATING operation
CM03FS(L)_30/5 CM03FS(L)_50/8 CM03FS(L)_100/12
S9 - 1.800 c/h according to IEC
60034
S9 - 1.800 c/h according to IEC
60034
S9 - 1.800 c/h according to IEC
60034
2,5 - 20 RPM 2,5 - 20 RPM 2,5 - 20 RPM
F
max
= 8,2 kN F
max
= 19,4 kN F
max
= 16,4 kN
F
avg
= 3 kN F
avg
= 7 kN F
avg
= 8 kN
Life time
*
1.800.000 starts 1.800.000 starts 1.800.000 starts
*
ATTENTION: life time is based on proper operation and maintenance according to SCHIEBEL operating manual
CYCLE = stroke of 40 mm in both directions with at least 30% of nominal force and the ability to accept 100% of nominal
force for at least 10% of the stroke
START = movement of at least 1% of stroke in both directions with a load of minimum 30% of nominal torque
