7 Parameter menu
Operating Manual Linear ACTUSAFE CMFS(L)
OM-ENGLISH-Failsafe-Linear-16xx-V2.00-2022.03.03
continued from previous page
Menu item Sub-menu item poss. setting Notes / comments
P19.7
System
Parameters
Calib.Setpoint
20mA
-10. . . +10%
This value is used to offset the input signal on analog
input 1 measured by the ACTUSMART control unit. The
measured mA-signal may be calibrated with an external
setpoint generator.
P19.8
System
Parameters
Calib.ext.act.val.
20mA
-10. . . +10%
This value is used to offset the input signal on the
external analog input 2 measured by the ACTUSMART
control unit. The measured mA-signal may be calibrated
with an external setpoint generator.
P19.12
System
Parameters
LCD Contrast 80. . . 150 The display contrast may be set with this parameter.
P19.15
System
Parameters
Welcome Menu 0; 1
Starts the actuator with the welcome menu on startup, if
set to 1.
P19.21
System
Parameters
LED Function
See "P1.7 - LED function" in section 7.1 on page 42.
P19.56
System
Parameters
LCD Inverse 0; 1 Inverts the display pixels.
7.18 Parameter group: Miscellaneous
Menu item Sub-menu item poss. setting Notes / comment
P20.1 Miscellaneous Language 0: German Defines the menu language
1: English
2: Russian
3: Czech
4: Spanish
5: French
6: Italian
7: Danish
8: Hungarian
9: Turkish
10: Greek
11: Polish
12: Serbian
13: Croatian
14: Bulgarian
15: Dutch
16: Romanian
17: Swedish
P20.2 Miscellaneous Smartcode Enables additional features by entering a Smartcode
P20.3 Miscellaneous
Restore
Backup
0: no action
1: Customer -
Restores all parameters to the customer backup
parametrization, without changing the end limits (P1.1
and P1.2) and the switch off torques and torque
limit(P2.1, P2.2 and P2.3).
2: Customer +
Restores all parameters to the customer backup
parametrization, including the end limits (P1.1 and P1.2)
and the switch off torques and torque limit(P2.1, P2.2
and P2.3).
3: Service -
Restores all parameters to the service backup
parametrization, without changing the end limits (P1.1
and P1.2) and the switch off torques and torque
limit(P2.1, P2.2 and P2.3).
continued on next page
