SCHIEBEL ACTUSAFE CMFS - Cm06 Fs(L)

Operating Manual Linear ACTUSAFE CMFS(L)
OM-ENGLISH-Failsafe-Linear-16xx-V2.00-2022.03.03 14 Mode of operation FS(L)
14.2 CM06FS(L)
ON-OFF & INCHING operation
CM06FS(L)_100/30 CM06FS(L)_170/25
S2 - 15 minutes according to IEC 60034 S2 - 15 minutes according to IEC 60034
2,5 - 60 RPM 2,5 - 60 RPM
F
max
= 22,4 kN F
max
= 22,4 kN
F
avg
= 15 kN F
avg
= 15 kN
Life time
*
10.000 cycles 10.000 cycles
MODULATING operation
CM06FS(L)_100/30 CM06FS(L)_170/25
S4 - 1.200 c/h - max. 50% DC according to IEC
60034
S4 - 1.200 c/h - max. 50% DC according to IEC
60034
2,5 - 30 RPM 2,5 - 30 RPM
F
max
= 22,4 kN F
max
= 22,4 kN
F
avg
= 15 kN F
avg
= 15 kN
Life time
*
1.200.000 starts 1.200.000 starts
CONTINUOUS MODULATING operation
CM06FS(L)_100/30 CM06FS(L)_170/25
S9 - 1.800 c/h according to IEC 60034 S9 - 1.800 c/h according to IEC 60034
2,5 - 20 RPM 2,5 - 20 RPM
F
max
= 22,4 kN F
max
= 22,4 kN
F
avg
= 10 kN F
avg
= 10 kN
Life time
*
1.200.000 starts 1.200.000 starts
*
ATTENTION: life time is based on proper operation and maintenance according to SCHIEBEL operating manual
CYCLE = stroke of 40 mm in both directions with at least 30% of nominal force and the ability to accept 100% of nominal
force for at least 10% of the stroke
START = movement of at least 1% of stroke in both directions with a load of minimum 30% of nominal torque
