PressControl 3000 – V1.3
10
2.2 Technical Data
Figure 2-2: Dimensions of the control unit
Technical Data
Display Liquid crystal display (128 x 240 pixels) with
background illumination, 16 lines of 40 columns
each, with touch screen functions
Keypad Touch screen
Interfaces USB
Mains connection 100 up to V AC / 50 up to 60 Hz max. back-up
fuse 16 A
Supply voltage 24 V DC
Current consumption 350 mA / 230 V or
700 mA / 110 V or
2.5 A / 24 V
Weight 5.5 kg incl. external power supply unit
Ambient temperature 0 up to 40° C
Air humidity up to max. 95% relative, non condensing
Protection type IP 54
Dimensions
~ 290
~ 320
~ 80
