8 Further integrated functions
SCHMIDT
®
PressControl 3000 – V1.3
39
Select the "Data Input" system function key.
Select the "Part check on/off" parameter.
Enter the value "1". To switch the function off again, enter the value "0".
As soon as the function is switched on, the input is queried as to whether a
part is available on an optionally mounted workpiece fixture.
If no part is in the fixture, the message ">Part insert>“ appears. The hand
lever will remain locked until the input transmits a signal. After inserting a
part, the message will disappear.
After the
press
process
, the m
ess
age "<Par
t rem
ove<“
will ap
pear.
The
message will disappear as soon as the part is removed. A possible incorrect
pressing can only be acknowledged after the workpiece has been removed.
parts inquiry
