EQUIPMENT SPECIFICATIONS
XH1500 XH1000
Cutting Width 180” (4.57 m) 126” (3.20 m)
Transport Width 89” (2.26 m) 88” (2.24 m)
Overall Width 189” (4.80 m) 139” (3.53 m)
Overall Length 205” (5.13 m) 205” (5.13 m)
Cutting Height 1.5”-19.25” (38mm - 144 mm)
HP Required (Min) 70 HP (52 kW) 70 HP (52 kW)
Cutting Capacity (Max) 5” (127 mm) 5” (127 mm)
Weight 6950 lbs (3152 kg) 6100 lbs (2767 kg)
Hitch Weight 2500 lbs (1134 kg) 2100 lbs (953 kg)
Blade Tip Speed
540 PTO
Center 848 FPM, 16,286 ft/min (4964m/min)
Wing 986 FPM, 16,030 ft/min (4886m/min)
1000 PTO
Center 850 FPM, 16,390 ft/min (4996m/min)
Wing 1002 FPM, 16,290 ft/min (4965m/min)
Gearbox Rating
Divider 275 HP (205 kW) 275 HP (205 kW)
Center/Wing 240 HP (179 kW) 240 HP (179 kW)
Wing Working Range 25º Down and 90º Up
Wing Float Range 25º Down and 45º Up
Driveline Size
Center and Wings CAT 6 CAT 6
540 RPM CV CAT 6 CAT 6
1000 RPM CV CAT 5 CAT 5
