12 05.00 | AGE-XY | Assembly and operating manual | en | 389007
3 Technical data
Size 50 63 80
Locking force at 6 bar [N] 235 370 580
Compensation stroke [mm] ±2.5 ±3 ±4
Max. distance of displacement force in Z [mm] 120 160 200
Min. pressure [bar]
Max. pressure [bar]
2
8
Min. ambient temperature [°C]
Max. ambient temperature [°C]
+5
+60
Noise emission [dB(A)] ≤70
Pressure medium Compressed air, compressed air quality
according to ISO 8573-1:2010 [7:4:4]
Repeatability [mm] 0.1
More technical data is included in the catalog data sheet.
Whichever is the latest version.
NOTE
Owing to the design, the compensation unit may also have a
clearance of approx. 0.06 even in locked state. Twisting in
locked state is possible up to a dimension of 0.1°.
Rigid centric locking can therefore not be guaranteed.
