General
6 05.00 | AGE-XY | Assembly and operating manual | en | 389007
l
Catalog data sheet of the purchased product *
l
Assembly and operating manuals of the accessories *
The documents labeled with an asterisk (*) can be downloaded
from schunk.com.
1.2 Warranty
If the product is used as intended, the warranty is valid for 24
months from the ex-works delivery date under the following
conditions:
l
Observe the specified maintenance and lubrication intervals
l
Observe the ambient conditions and operating conditions
Parts touching the workpiece and wear parts are not included in
the warranty.
1.3 Scope of delivery
The scope of delivery includes
l
Compensation unit AGE-XY in the version ordered
l
fastening screws (pre-installed)
l
cylindrical pin (in the accessories pack)
1.4 Accessories
A wide range of accessories are available for this product
For information regarding which accessory articles can be used
with the corresponding product variants, see catalog data sheet.
1.4.1 Sensors
Designation Type
Magnetic switch MMS
Tab.: Overview of the compatible sensors
l
Exact type designation of the compatible sensors see catalog.
l
Information on handling sensors is available at schunk.com or
from SCHUNK contact persons.
1.4.2 Sealing kit
Seal kit for ID number
AGE-XY 50 5516360
AGE-XY 63 0371043
AGE-XY 80 5517030
Tab.: ID.-No. of the seal kit
contents of the sealing kit,}7 [/21].
