Maintenance
40
03.00 | MEG 50 EC | Assembly and Operating Manual | en | 389201
7.2 Lubricate gripper
SCHUNK recommends the listed lubricant.
During maintenance, treat all greased areas with lubricant. Thinly
apply lubricant with a lint-free cloth.
Lubricant point Lubricant
Metallic sliding surfaces Isoflex-Topas NCA 52
Position of the greasing areas
Ø Move the gripper to the "closed" position and lubricate the
greasing areas.
Ø Move the gripper to the "open" position and lubricate the
greasing areas.
Ø Fully open and close the gripper several times.
7.3 Disassembly and assembling
This product must not be disassembled for maintenance.
CAUTION
Material damage due to improper disassembly!
Incorrect works can cause damage to the mechanics and internal
electronics.
• Disassembly or opening of the product is not permitted.
• Only allow SCHUNK to repair the product.
