Troubleshooting
44
03.00 | MEG 64 EC | Assembly and Operating Manual | en | 389203
6.2 Product does not execute a complete stroke
Possible cause Corrective action
Dirt deposits between basic jaws and
guidance.
Disassemble and clean the product.
Mounting surface is not sufficiently flat. Check the evenness of the mounting surface.
Component part defective. Send product with a SCHUNK repair order or
dismantle product.
6.3 The gripping force drops
Possible cause Corrective action
Too much grease in the mechanical
movement space.
Clean and lubricate product. Maintenance
[
}
45]
6.4 Product opens or closes jerkily
Possible cause Corrective action
Too little grease in the mechanical guiding
areas.
Clean and lubricate product.
Maintenance [
}
45]
Mounting surface is not sufficiently flat. Check the evenness of the mounting surface.
Mechanical connection [
}
18]
Loading too large. Check permissible weight and length of the
gripper fingers.
Technical data [
}
16]
