SCHUNK PGN-plus-P 64 - Tightening Torques

Maintenance
46
05.00 | PGN-plus-P | Assembly- and Operating Manual | en | 0389753
Ø Fasten the cover (6) with the screws.
Tightening torque: Tightening torques [
}
46]
Ø Fasten the cover (11) with the screws.
Ø Assemble gripper on the machine/system.
Ø Connect all compressed air lines.
7.5.4 Tightening torques
Item Mounting PGN-plus-P
40 50 64 80 100 125 160 200 240
1 Screw Cylinder
head [Nm]
1.2 1.2 6.1 10 15 25 49
65.5
85
2 Screw Cover
[Nm]
0.27
1.2 1.2 3.1 3.1 3.1 2.2 4.3 4.3
