SCHUNK PGN Series User Manual

Technical Data
11.00 | PGN | Assembly and Operating Manual | en | 389286
17
3 Technical Data
Designation PGN
Pressure medium Compressed air,
compressed air quality
according to ISO 8573-1:7 4 4
Nominal working pressure [bar] 6
Min. pressure [bar]
without gripping force maintenance
with gripping force maintenance
2.0
4.0
Max. pressure [bar]
without gripping force maintenance
with gripping force maintenance
8.0
6.5
Ambient conditions and operating conditions
Designation PGN
Ambient temperature [°C]
min.
max.
-10
+90
IP protection class * 40
Noise emission [dB(A)] ≤ 70
* For use in dirty ambient conditions (e.g. sprayed water, vapors,
abrasion or processing dust) SCHUNK offers corresponding
product options as standard. SCHUNK also offers customized
solutions for special applications in dirty ambient conditions.
More technical data is included in the catalog data sheet.
Whichever is the latest version.

SCHUNK PGN Series Specifications

General

Actuation	Pneumatic
Number of Fingers	2
Material	Aluminum
Type	Parallel gripper
Holding force without pressure	0 N
Operating pressure	4 bar - 8 bar
