SCHUNK PGN Series User Manual

General
11.00 | PGN | Assembly and Operating Manual | en | 389286
7
1.3 Scope of delivery
The scope of delivery includes
• 2-Finger Parallel Gripper PGN in the version ordered
• Accessory pack
Content of the accessory pack:
• 2x O-ring for hose-free direct connetion
• 1x Switching cam (PGN 100, 125, 160)
• 2x clamping sleeve (PGN 200, 300)
• 2x Cylindrical pin
• 2x Locking screw
ID.-No. of the accessory pack
ID number
Size
PGN PGNV/HT
PGN 100 5509375 395509375
PGN 125 5509378 395509378
PGN 160 5509379 395509379
PGN 200 5510114 395510114
PGN 300 5510608 395510608
1.4 Accessories
A wide range of accessories are available for this product
For information regarding which accessory articles can be used
with the corresponding product variants, see catalog data sheet.
1.4.1 Seal kits
ID.-No. of the seal kit
Size
ID number
PGN PGN V/HT
PGN 50 0370749 30012207
PGN 64 0370500 0370748
PGN 80 0370501 0370725
PGN 100 0370502 0370737
PGN 125 0370503 0370652
PGN 160 0370504 0370622
PGN 200 0370496 0370857
PGN 300 0370796 0370848
PGN 380 5516411 0370927

SCHUNK PGN Series Specifications

General

Actuation	Pneumatic
Number of Fingers	2
Material	Aluminum
Type	Parallel gripper
Holding force without pressure	0 N
Operating pressure	4 bar - 8 bar
