SCHUNK PGN Series User Manual

Assembly
11.00 | PGN | Assembly and Operating Manual | en | 389286
19
Mounting material
Item PGN
50 64 80 100 125 160 200 300 380
1 4 x M4 4 x M5 4 x M5 4 x M6 4 x M8 4 x M8 4 x M10 4 x M16 4 x M20
2 2 x M3 2 x M4 2 x M5 2 x M6 2 x M8 2 x M8 2 x M10 2 x M12 2 x M16
3 4 x M3
x 25
4 x M4
x 16
4 x M4
x 20
4 x M5
x 25
4 x M6
x 30
4 x M6
x 30
4 x M8
x 40
4 x M12
x 55
4 x M16
x 76
4 Ø3H7 Ø4H7 Ø4H7 Ø5H7 Ø6H7 Ø6H7 Ø8H7 Ø10H7 Ø10H7
NOTE
• For mounting from the rear or side fix the module on the pro-
posed fixing bores.
• Mount the module using the mounting bores.
• Mount the top jaws using the mounting bores provided.
• In case of lateral fastening, the adapter plate must have an un-
dercut above the fastening bores in order to avoid a jamming of
the base jaws.

SCHUNK PGN Series Specifications

General

Actuation	Pneumatic
Number of Fingers	2
Material	Aluminum
Type	Parallel gripper
Holding force without pressure	0 N
Operating pressure	4 bar - 8 bar
