SPECIFICATIONS
MECHANICAL PARTS REMOVAL/REPLACEMENT
16
SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
(A)
(B) x 4
(C)
The outer handle cover cap (#A5435) has
a small opening so the end of a at head
screwdriver may t into it. Use a small at
head screwdriver to pop out the cap.
Step 4b:
Remove the (a) 7/16-14 nylock
nut (#1137027), ( b) f our w ashers
(#10357-03641) a nd
(c) 7/16-14 x 4.5” black at head socket
screw (#10537-08048).
Step 5:
Rest the unsecured assembly link blade on
the cloth, so not to damage the blade.
Step 6:
Note: Make note of washer locations for
replacement purposes.
