mAgnET cABLE rEmovAL
SPECIFICATIONS
ELECTRICAL PARTS REMOVAL/REPLACEMENT
68
SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
Mid-Cable
Magnet Cable
Frame channel
The mid-step counter cable (#A5409)
is hidden within a frame channel on the
upper part of the main frame behind the
brake, carefully pull out the cable to
access the housing connection between the
mid-cable and the magnet cable (#A5410).
Step 2:
Remove the console and lower/upper covers according to the “Lower/Upper Cover Removal” process.
Step 1:
Disconnect the mid and magnet cables.
Step 3:
To Next Page
