Seaga Quick Break Combo QB2000 - Adjusting Coils

13QB2000 9.2022 vers 1.0
Figure 8 – Remove the tray
Tray 130 Harness
Li tray free
Adjusng Coils
If you are required by a locaon to vend a product of a non-standard size, you may need to order a dierent
coil and install it. Replacing a coil is easier with the tray removed, as described in the last secon. To replace a
coil:
1. Remove the coil from the coil driver by liing the back of the coil up o the coil driver. You will need to
move the boom of the coil clear of the coil driver to completely remove the coil. See Figure 9
2. Align the new coil end with the front of the product tray, which gives the coil beer contact with the prod-
uct. The posion of the coil in the coil driver is adjustable to assist you in aligning the new coil at the front
of the product tray. See Figure 9.
This coil adjustment can be done for all the selecons on snack or entree product trays. See Figures 6 and 6a
for examples of the locaon of home posion on the coils.
Figure 9 – Removing and Aligning a Coil
Apply pressure to the
straight part of the coil
that is inserted into the
Coil Driver. Li up the
Coil to remove.
Coil Driver with
three (3) adjustment
opons
Back of Product Tray
Li Coil
