Seaga Quick Break Combo QB2000 - Replacing Snack Motors

14QB2000 9.2022 vers 1.0
If you are experiencing vending issues with certain products, you may need to adjust the coil rotaon to beer
provide the momentum to push the snack o the tray and into the delivery area. To adjust the coil rotaon:
1. Squeeze the two tabs on the back of the coil driver and pull the coil driver and coil toward the front of the
tray to remove it.
2. Turn the coil clock-wise 1/8 of a rotaon.
3. Reinsert the coil driver with coil aached back into the motor, through the back wall of the tray.
4. Load the tray and perform at least 5 (ve) test vends to insure a proper vend.
5. If the item does not vend consistently, repeat another 1/8 of a rotaon unl you are condent of consistent
vend funcon.
Figure 10 – Coil Rotaon Adjustment
Squeeze two tabs on
the back of the Coil
Driver
Pull the Coil Driver
and Coil forward;
Rotate 1/8 of a turn
and reinsert back
into product tray.
Replacing Snack Motors
As one of the moving parts of the vending system, vend motors experience regular wear and may need to be
replaced on occasion. To replace a vend motor, remove the tray as instructed in the Remove Trays secon of
this manual and then remove the coil driver and coil as shown in Figure 10.
Note: Never use a Snack motor in the Beverage Secon.
1. Unplug motor harness.
2. Unscrew the two screws as shown in Figure 11.
3. Replace motor and plug motor harness back in.
4. Reinstall coil driver so that coil is in home posion
(see Figures 6 and 6a for coil home posion examples).
5. Perform at least 5 (ve) test vends to insure a proper vend.
Unplug motor
harness
Figure 11 –Motor on Snack Tray
Unscrew two
screws
Squeeze to
remove coil
driver
