REFRIGERATION
Yourbeveragesarekeptcoldbyahighe󰀩ciencyrefrigerationsystemhavingtwoaircirculationfans
to chill the cans and bottles. The refrigeration unit can be easily accessed by opening the Front Door.
Removethesinglebluethumbscrewfromthecenterooroftherefrigerationdeckandremovethe
partition wall. Remove the two screws holding the handles in place Figure 20.
The refrigeration deck is a modular system consisting of Compressor, Condenser, Condenser fan,
Evaporator, Evaporator Fans, Accumulator or Dryer, and Temperature Sensor which communicates to
theVMC.Thetemperatureispre-setatthefactoryfore󰀩cientande󰀨ectiveoperation.
Figure 20 – Refrigeration unit
Condenser
Gently clean
nsona
regular basis
Remove three
screws
Compressor
Make sure you unplug wire harnesses and feed the harnesses back through the divider wall before
pulling the refrigeration deck all the way out of the machine. Do not tip the refrigeration deck more
than 20° in any direction.
Unplug the wire harnesses on the right side of the deck and feed the connectors back through the
grommet(Fig.21).Thiswillpreventdamagetotheconnectorswhenthedeckisremoved.
Figure 21 – Refrigeration deck wire harnesses
Wire Harnesses
