Seaga Quick Break Combo QB2000 - Removing Bill Validator

26QB2000 9.2022 vers 1.0
Figure 22 – Bill Validator
Tab
(4) Mounng Nuts
Bill Collecon Box
Lower Housing
REMOVING BILL VALIDATOR
From me to me it may be necessary to remove the Bill Validator for cleaning and clearing jams.
a.Disconnect the power to the machine – this is very important to avoid damaging not only the bill
validator but your VMC. Failure to disconnect power before performing this operaon will void your
warranty.
b. Unlock and open the Front Door
c. Push Bill Validator Tab forward and slide Bill Storage Box up to remove
d. Disconnect Bill Validator from Wire Harness
e. Remove the Four (4) Mounng Nuts.
Tab
