25QB2000 9.2022 vers 1.0
c. Li up on the white lever on the top le side of the coin mechanism
d. Tilt the Discriminator assembly forward and li o main housing. Note: the discriminator will sll be at-
tached by a cable.
e. Loosen the three (3) Mounng Screws
f. Li Changer and remove.
Bill Validator
The Bill Validator allows your customers to pay for their purchase with paper currency. Your Bill Validator is
installed at the factory, and is set to validate $1, $5 and $10 bills, but will not accept bills if the coin tubes are
empty. The Bill Validator veries, accepts and stores paper currency but change is given in coins only.
Bill Validator Capacity
The Bill Storage Box will hold approximately 250 bills.
Bill Retrieval
The bills your customers spend are kept in the Bill Collecon Box.
a. Unlock and open the Front Door
b. Open door located on top of bill collecon box and li out bills
c. Close top door on bill collecon box aer bills are retrieved
