12QB2000 9.2022 vers 1.0
Removing Snack Trays
It is somemes necessary to replace a snack tray or you may nd it easier to work on certain elements of a tray
if it is removed from the vending system cabinet.
Figure 7 – Tray Harnesses
Tray 110 Harness
Tray 120 Harness
Tray 130 Harness
Squeeze tabs and pull
Tray Harness connector
free.
To remove a snack tray:
1. Remove all product from the tray you want to remove.
2. Reach in and squeeze the two cable release tabs on the top and boom of the connector and unplug the
proper tray harness.
3. Rest the tray harness on top of the tray you are removing to keep it out of the way.
4. Flip the release lever on the right side of the tray to face toward the back of the machine and raise the
front wheels out of the side rails unl you feel the roller come to the built in rail stop.
5. With a rm hold on the tray, li up to release the roller from the rails on the sides of the cabinet.
6. Pull the tray free and place it on a sturdy, at surface to complete your work.
