Seaga Quick Break Combo QB2000 - Page 16

16QB2000 9.2022 vers 1.0
Figure 13 – Retainer in Load Posion
Retainer
2. 20 oz/591 ml Boles are loaded laying down, two deep in each column. Load the rst bole so that the top
touches the back of the column. The next bole should also be loaded with the top toward the back of the
column, posioned against the boom of the rst bole.
3. 12 oz/355 ml Cans (not slim cans) are loaded laying down, three deep in each column. Load cans with the
top of the rst can touching the back of the column. The boom of the next can should be touching the
boom of the rst can. The third can should be loaded with the top touching the top of the second can.
4. Finish loading to the top of the column, not exceeding maximum capacity (see chart), making sure the
items are not lted or skewed in the column.
5. With column loaded, li the Retainer Gate back into sales posion using the Locking Tab and push down to
lock.
Figure 14 – Loaded Product with Retainers Secured
Retainer
Adjusted within ½” of
product
Locking Arm Secured
