IMAG 4700r INSTRUCTIONS
Seametrics • 253.872.0284 Page 5 seametrics.com
Dimensions
Remote Display
GENERAL INFORMATION
4.150” (105.4mm)
Install security seals during
installation if regulations require.
Note: ‘L’ dimension is total from liner face to liner face
3.500” (88.9mm)
4.000” (101.6mm)
6.840” (173.7mm)
4.375”
(111.1mm)
5.200”
(132.1mm)
Ø 0.200”
(5.08mm)
Ø 5.285”
(134.2mm)
H
1
L
T
ID
H
iMAG 4700
Meter Size
L H
1
H T ID
Bolt
Holes
Shipping Weight
iMAG 4700r
inch mm inch mm
inch mm
inch mm inch mm
#
lbs
Kg
2” 7.9 200 7.8 198 10.8 274 .62 15.7 1.76* 45* 4
22 10
3” 7.9 200 8.35 212 12.1 307 .62 15.7 2.68* 68* 4
28 12.7
4” 10.12 257 8.6 218 13.1 332 .62 15.7 3.12 79
8
43 19.5
6” 12.09 307 9.4 239 14.9 378 .69 17.5 5.05 128
8
59 27
8” 14.14 359 10.4 264 17.15 435 .69 17.5 6.44 164
8
78 35
10” 18.08 459 11.5 292 19.5 495 .69 17.5 8.61 219
12
135 61
12” 19.68 500 12.5 317 22 559 .81 20.6 10.55 268
12
175 79
Flanges Standard ANSI 150 lb. drilling Cable 1 lb.
