IMAG 4700r INSTRUCTIONS
Seametrics • 253.872.0284 Page 7 seametrics.com
INSTALLATION
12345
1X
2X
2X
2X
1X
5X
5X
5X
Reduced Pipe
Two Elbows In Plane
Two Elbows, Out Of Plane
Expanded Pipe
Swirling Flow:
Propeller Meter
Partially Open
Buttery Valve
1X
1X
1X
1X
Swirling Flow:
iMAG
iMAG
iMAG
iMAG
iMAG
iMAG
Straight Pipe Recommendations (X=diameter)
NOTE: These congurations are to be used as general guidelines and do not cover every possible installation. A
combination of two or more obstructions will require additional straight pipe. If there is any concern about the
length of pipe required for a specic application, please contact your local dealer.
