Securlift Secur3 - Page 34

follows: IM_SEC3_02.01_en.docx
34/70
CAN1 (serial connection to car)
1 CH  CAN high
2 CL CAN low
3 +24 VDC
4 GND
5 +24 VDC
6 GND
CAN2 (serial connection to landings and
multiplex)
1 CH  CAN high
2 CL CAN low
3 +24 VDC
4 GND
5 +24 VDC
6 GND
CAN3 (serial connection to inverter)
1 CH  CAN high
2 CL CAN low
3 +24 VDC
4 GND
5 +24 VDC
6 GND
DOM (monitoring BYPASS EN 81-20)
1 input monitoring BYPASS EN 81-20
2 input monitoring BYPASS EN 81-20
LED’s which are monitoring relay are connected in series to relay coil.
