LED’s
In the following tables all LED symbols are shown with power ON, with car parked at bottom floor, after
reset drive has been accomplished.
 = lit
 = off
 = blinking
SUPPLY  safety circuit START: AM
circuit braker, phase
supervision, pit stop sw., OSG
rope tensioner
SHAFT  shaft static safety circuit: final
limit sw., buffers, OSG, etc.
CAR  car safety circuit: stop sw.,
inspection sw., safety gear
sw.
SWING DOORS  landing swing doors safety
circuit
CAR DOORS  car door safety contact
LOCKS  landing doors locks contacts
TR  future use
DZM  future use
IU   UP magnetic switch
ID   DOWN magnetic switch
IZ  DOOR ZONE magnetic switch
IM  Car at floor magnetic switch
IZ1  DOOR ZONE magnetic switch
(ELGO LIMAX2)
IZ2  DOOR ZONE magnetic switch
(ELGO LIMAX2)
IF  Input pit inspection box
Connectors
• SCB = connessione alla scheda SEC-3Q
SH1 (shaft)
1
3
SUPPLY

PST: Pit Stop Switch, pit ladder, pit
inspection box
RTC: Over speed governor rope
tensioner
5
7
SHAFT

FLS: Final Limit Switches
X: buffers
Overspeed Governor
SH2 (landing doors)
1
3
SWING
DOORS

PM: manual landing swing doors
5
7
LOCKS

CP: landing doors locks
SC1 (car)
1
3
CAR

SGS: Safety Gear Switch, Overspeed
Governor
SBM: inspection box, Stop button
LPK: Car Locking Pin
FLS: Final Limit Switches
5
7
CAR DOORS

CPC: Car Door Contact
9
RB/RDF: Recall Drive Switch
