follows: IM_SEC3_02.01_en.docx
53/70
CAN UP (supply and serial link)
1 CAN H
2 CAN L
3 +24 VDC
4 GND
5 +24 VDC
6 GND
CAN DN (supply and serial link)
1 CAN H
2 CAN L
3 +24 VDC
4 GND
5 +24 VDC
6 GND
UPB (up button)
1 up CALL input (+)
2 up REGISTERED output (-)
3 up REGISTERED (+24 VDC)
4 up CALL (GND)
DNB (down button/call)
1 down CALL input (+)
2 down REGISTERED output (-)
3 down REGISTERED (+24 VDC)
4 down CALL (GND)
PKH (option inputs)
1 PRL – Priority call
2 OSS – Out of Service key
3 LOL – call disable
4 VIS – visitors delivery
5 FET/FEB – Floor Extension (Top/Bottom)
Car preference call
6
7 +24 VDC
8 GND
OUT (option output)
1 OSI – Out of Service indication
2 HSL – car Here indication
3 Fireman’s drive indication
4 FLD – Full Load indication
5 BEEP – EN 81-70
6 +24 VDC
HLL (hall lanterns and gong output)
1 LAL - UP lantern
2 LAL - DOWN lantern
3 FET/FEB – Car preference call accepted
4 VIS – visitors delivery
5 +24 VDC
6 GND
NOTE
if SEC-2L used for connect the pit inspection box:
Settings SW1/6=ON SW1/8=ON
Input connector PKH
1 normal/inspection
2 UP direction
3 DOWN direction
4 Not used
5 Not used
6
7 +24 VDC
8 GND
ATTENTION:
SEC-2L DEDICATED TO PIT
INSPECTION BOX
DO NOT USE IT FOR OTHER
FUNCTIONS!
