17. Connect HV Cables of the X-ray Tube.
T erminal Pins of HV Cables are extremely delicate and they
are easily damaged. Take particular care to handle them
carefully. Make sure that they are all straight and that the
splits in the pins are open (parallel to sides).
Prepare the High Voltage terminals that will be installed in the X-ray Tube
receptacles. Apply Silicone Paste over the entire surface of the Plug
including the Pins.
Carefully connect cables to their related receptors of the T ube and fix
their nuts tightly.
18. Fasten HV cables to lateral sides of Swivel Arm with the clamp on the
carriage of the T ube Collimator Assembly. Give the cable length enough
to enable movements of the of Swivel Arm (refer to Illustration 3-9).
Tube HV Cables may also be tied up to a ceiling pole to avoid
collisions and to easy movements of the system.
19. Install the Top Cover of the Columm with the supplied screws (refer to
Illustration 3-9).
20. Install the Decorative Base of the Columm (pressing it) (refer to
Illustration 3-9).
21. Remove now the Safety Locking Rod from the Central Carriage (refer to
Illustration 3-9).
Note .
