b. Connect to the Control Unit Board (A3194--XX) all connectors and
wires from the main harness (J1, J2, wires to TS1 and TS2) (refer
to Interconnections Map A6541- 03-S).
c. Connect to the Generator the cables from the main harness
(Stator, Bucky and ground (GND) cables routed directly from the
Column) (for these connections refer to Interconnections Map
A6541- 03-S and also to Generator Service Manual).
d. Route the Height Motor cable (A3386--01) through the lower
cables entrance of the Control Unit and plug in to Connector TS3
of the Control Unit Board (A3194--XX).
e. Connect directly the ground cables (GND) from the Column and
Control Unit Box to the Main ground stud (GND) of the Generator.
f. Cables to be connected directly in the Generator Cabinet must be
routed through the lower cables entrance of the Control Unit.
g. Ve rify that the transformer and the fuses of the Control Unit are in
accordance to the power line (refer to Interconnections Map
A6541- 03-S).
h. Route the Power cable (A3153--02) through the lower cables
entrance of the Control Unit Box. Connect one of its ends to
Terminals TS1 of the Control Unit and, in the other end, install a
suitable connector to the wall plug. (Refer to Interconnections Map
A6541- 03-S).
16. Close the Control Unit door.
Do not plug the Control Unit until specifically advice in this
Document.
Power supply connections must be in compliance with Local
Codes.
Note .
Note .
