Guardian Field Support Manual
Crimp Terminal:
Connection: Connects a cut wire to a threaded
bolt or screw
Size: Blue Ring 6.3mm
Adjustment: Automotive crimps must be used to
crimp terminal
Function: For power connection
Crimp Terminal:
Connection: Connects a cut wire to a threaded
bolt or screw
Size: Blue Ring 10mm
Adjustment: Automotive crimps must be used to
crimp terminal
Function: For power connection
Zip/Cable Ties:
Connection: For cable formation, relief and safe
cabling
Size: 188mm x 4.8mm
Adjustment: Trim excess after use
Function: Use to keep cabling away from
standard vehicles operation
Blanking Grommet:
Connection: To provide quality of install if a hole
in the dashboard is required for cable wiring
Size: 36.3mm (25mm hole size)
Adjustment: punch or cut a hole to allow cables
through the centre
Function: To cover up a 25mm drill hole in the
dashboard if drilling is required
To Next Page
