Guardian Field Support Manual – Section 2
45
Use the 2 hose clamps on the outer slots to
secure the vibration motor to the mount.
Adjusting the Mounts:
Using an 8mm socket and your impact driver
to tighten the hose clamps (this is the
easiest and fastest way to mount).
The hose clamps can then be rotated to the
final position prior to tightening them.
Secure any excess hose clamp with the zip
ties provided.
Important Points to Note:
The hose clamps must fall into the slots on
the Vibration Motor so that the motor cannot
slide out.
Ensure that the hose clamps are tightened
so the motor cannot move or slide around
during normal vehicle operation.
