Char Description
IEC VINV IEC Very Inverse [VINV]
IEC EINV IEC Extremely Inverse - Characteristic
IEC LINV IEC Long Time Inverse - Characteristic [LINV]
RINV R Inverse [RINV] - Characteristic
HV Fuse Overcurrent characteristic “HV Fuse”
FR Fuse Overcurrent characteristic “FR Fuse”
IEEE MINV IEEE Moderately Inverse [MINV] - Characteristic
IEEE VINV IEEE Very Inverse [VINV]
IEEE EINV IEEE Extremely Inverse - Characteristic
EF Curve Overcurrent characteristic “EF Response Curve”
RXIDG Overcurrent characteristic “RXIDG”
Reset Mode
Selection list referenced by the following parameters:
• ╚═▷ IG>> . Reset Mode•
Reset Mode Description
instantaneous Instantaneous reset: when the current drops below the pickup setting, the TOC time
resets to zero within 2 cycles.
de󰈛nite time Reset after a 󰅰xed time.
(Remark: This delay is then de󰅰ned by the parameter »t-reset delay«.)
inverse time Calculated reset, based on the selected characteristic.
Char
Characteristic
Selection list referenced by the following parameters:
•
╚═▷ I2> . Char
•
Char Description
DEFT DEFT
IEC NINV IEC Normal Inverse
IEC VINV IEC Very Inverse [VINV]
IEC EINV IEC Extremely Inverse - Characteristic
143WIC1WIC1-2.0-EN-REF
13 Selection Lists
