Seg WI Series Reference Manual

IG>> . Reset Mode [Protection Para / IG>>]
instantaneous If: IG>> . Char = DEFT
• instantaneous, de󰊟nite time•
If: IG>> . Char = IEC NINV
• instantaneous, de󰊟nite time, inverse time•
If: IG>> . Char = IEC VINV
•
instantaneous, de󰊟nite time, inverse time
•
If: IG>> . Char = IEC EINV
•
instantaneous, de󰊟nite time, inverse time
•
If: IG>> . Char = IEC LINV
• instantaneous, de󰊟nite time, inverse time•
If: IG>> . Char = RINV
•
instantaneous, de󰊟nite time, inverse time
•
If: IG>> . Char = HV Fuse
• instantaneous, de󰊟nite time•
If: IG>> . Char = FR Fuse
•
instantaneous, de󰊟nite time
•
If: IG>> . Char = IEEE MINV
•
instantaneous, de󰊟nite time, inverse time
•
If: IG>> . Char = IEEE VINV
•
instantaneous, de󰊟nite time, inverse time
•
If: IG>> . Char = IEEE EINV
•
instantaneous, de󰊟nite time, inverse time
•
If: IG>> . Char = EF Curve
•
instantaneous, de󰊟nite time
•
If: IG>> . Char = RXIDG
•
instantaneous, de󰊟nite time
•
╚═▷ Reset Mode
P.1
Reset Mode
IG>> . tReset [Protection Para / IG>>]
0.1s
Only available if:
• IG>> . Reset Mode = de󰊟nite time•
0.00s . . . 60.00s P.1
Reset delay for intermittent phase failures (INV characteristics only)
82 WIC1 WIC1-2.0-EN-REF
9 Protection Parameter
9.12.2 IG>>: Settings
